South Pacific Tyres; John Thompson boiler demolition 1; burner end
Expand/collapse
Details
PhotographerBill Prebble
DescriptionThis boiler was made by a John Thompson subsidiary in Hamilton; it was rated at 35 000 pounds/16 000 kg per hour from and at 100 degrees C; noticeably less at its working pressure of 250 pounds per square inch (17 bars).
The burner could use natural gas or oil, and has been swung outwards. At bottom right is the blower which fed air to the burner.
Originally, the outside chimney was 1.8 metres bore, but in 1972-73 the bore was reduced to 0.9 metres; the gas would move four times as fast, and hopefully it would send any smoke up through the atmospheric inversion layer; friction per foot would be five times what it had been, so a fan was necessary.
There are six panels, each with two handles, which can be removed to allow the flue-gas tubes to be cleaned.
These eight images have been selected from 20 taken as the boiler was carved up; they show the main details and how the boiler worked.Date TakenNovember 2007
DescriptionThis boiler was made by a John Thompson subsidiary in Hamilton; it was rated at 35 000 pounds/16 000 kg per hour from and at 100 degrees C; noticeably less at its working pressure of 250 pounds per square inch (17 bars). The burner could use natural gas or oil, and has been swung outwards. At bottom right is the blower which fed air to the burner.
Originally, the outside chimney was 1.8 metres bore, but in 1972-73 the bore was reduced to 0.9 metres; the gas would move four times as fast, and hopefully it would send any smoke up through the atmospheric inversion layer; friction per foot would be five times what it had been, so a fan was necessary.
There are six panels, each with two handles, which can be removed to allow the flue-gas tubes to be cleaned.
These eight images have been selected from 20 taken as the boiler was carved up; they show the main details and how the boiler worked.
Date TakenNovember 2007 Depicts or relates to
